The ENTEXS is the smallest ethanol solvent-based extraction system we offer. Equipped with modules that can be configured to the user’s needs. A fully automated extraction system that can process 300 lbs of biomass per day.
BATCH RATE
BATCH SIZE:Â 15 LBS THROUGHPUT
CAPACITY:Â 300 LBS / 16HRS
COOLING METHOD:Â LN OR CASCADE CHILLER
TEMPERATURE RANGE:Â DOWN TO -80 C
SYSTEM MODULES
BATCH CENTRIFUGE
SOLVENT STORAGE TANK (INSULATED)
TINCTURE STORAGE TANK (INSULATED)
MAG DRIVE RECIRC PUMPS
HEAT EXCHANGERS
FILTRATION SKID (PARTICULATE AND COLOR REMEDIATION)
EVAPORATION AND DISTILLATION SKID
RISING FILM EVAPORATOR
FALLING FILM EVAPORATOR
WIPED FILM SHORT PATH DISTILLATION
HTF SUPPORT SYSTEM
MAG DRIVE GEAR PUMPS
VALVES (MANUAL AND PNEUMATIC)
HIGH VAC (MTORR) SYSTEM W/ ROOTS BLOWER COLD TRAP
ELECTRICAL SPECIFICATIONS
VOLTAGE:Â 208/240/480 (CONFIGURABLE)
POWER:Â 45 KW (LN COOLING) / 65 KW (CASCADE)
ELECTRICAL RATING:Â C1D2 MINIMUM RATED
MECHANICAL SPECIFICATIONS
FOOTPRINT: 12’X10’X6’
TEMPERATURE RATING:Â -80 C EXTRACTION / 200 C DISTILLATION
PRESSURE RATING:Â FULL VACUUM TO 150 PSIG SOLVENT HOLDING
VOLUME:Â 120 GALLONS HMI
INTERFACE:Â 24 INCH TOUCH PANEL
CONTROLLER:Â FPGA BASED INDUSTRIAL CONTROLLER WITH WATCHDOG UL LISTED COMPONENTS
